NOS 1982-1983 Yamaha XT550 Service Manual OEM Repair Shop Guide
For sale is a Genuine Yamaha OEM Service Manual for the 1982-1983 XT550 dual-sport motorcycle. This is the original, physical factory-issued shop manual used by dealership technicians, offering far more technical depth than standard owner's manuals or aftermarket guides.
Technical Specifications
- Brand: Yamaha Genuine OEM
- Part Number: LIT-11616-XT-51 (Also replaces LIT-11616-03-00)
- Model Coverage: 1982 Yamaha XT550J & 1983 Yamaha XT550K
- Format: Softcover / Shop Binder Ready (Pre-punched holes)
Comprehensive Coverage
This manual is the "bible" for the XT550 and includes:
- Engine & Transmission: Complete teardown and rebuild specs for the 558cc single-cylinder engine.
- Carburetion: Detailed tuning and jetting for the unique YDIS (Yamaha Duo Intake System).
- Chassis: Front fork and Monocross rear suspension service procedures.
- Electrical: Full-color fold-out or detailed black-and-white wiring diagrams and ignition troubleshooting.
- Specs: Every torque value, fluid capacity, and wear limit required for a 100% factory restoration.
Key Features
- OEM Accuracy: Contains the exact clearances and settings intended by Yamaha engineers—no guesswork.
- Restoration Essential: A must-have for anyone maintaining or restoring a classic 80s dual-sport to showroom condition.
- Original Print: This is a vintage physical copy, providing the crisp diagrams and photos often lost in modern digital scans or reprints.
selling as pictured.
more than welcome to pick up at shop in butler pa & save shipping.
