2009 Harley-Davidson Softail Models Factory Service Manual.Document OverviewPart Number: 99482-09Coverage: Complete mechanical, electrical, and structural repair guidelines for all 2009 Harley-Davidson Softail lineup configurations.Dimensions: As shown next to the measuring tape, the manual stands at approximately 11 inches (28 cm) tall.Core Sections Inside This ManualThis technical manual is divided into several main chapters containing detailed engineering schematics, step-by-step tear-down instructions, and precise torque specifications:Maintenance: Fluid capacity specifications, torque values, and scheduled maintenance checklists.Chassis: Wheel assembly, steering head, front forks, rear suspension setup, and brake system overhauls.Engine & Drive: Full rebuild procedures for the air-cooled, balanced Twin Cam 96Bâ„¢ engine, primary drive, clutch, and 6-speed transmission.Fuel System: Electronic Sequential Port Fuel Injection (ESPFI) diagnostics and fuel tank servicing.Electrical: Wiring routing, fuse block setups, and basic component replacements (Note: High-level troubleshooting is typically supplemented by the companion 99498-09 Electrical Diagnostics Manual).Models CoveredThis factory documentation explicitly covers all variations within the 2009 Softail family line, including:FXST Softail StandardFLSTC Heritage Softail ClassicFLSTF Fat BoyFLSTN Softail DeluxeFXSTC Softail CustomFLSTSB Softail Cross BonesFXCW / FXCWC Softail Rocker / Rocker Custom
